Specifications

GAS Supply

• Gas source:

3 gas, O2,N2O,Air

• Gas source pressure gauge:

3 gas, O2,N2O,Air

• Output pressure of regulator: 280kpa～300kpa

• Security valve release pressure:≦10 kpa

• Pressure of pipeline inlet:

O2,280kPa～600kPa/41Psi～87Psi, ≦180L/min

N2O,280kPa～600kPa/41Psi～87Psi, ≦180L/min

Air,280kPa～600kPa/41Psi～87Psi, ≦180L/min

• N2O cut off valve protection: when O2 is lost, N2O will be cut off.

Flow Meter

• 6 tubes high precision flow meter with O2&N2O linkage device

• Gas scale:

O2: two tubes, 0～1L/min,1.1L/min～10L/min;

N2O: two tubes, 0～1L/min,1.1L/min～12L/min;

Air: two tubes, 0～1L/min,1.1L/min～15L/min;

• Precision: At 20 degree, atmospheric pressure is 101.3kPa, the precision of flow meter is level:2.5.

• O2&N2O linkage device, to make insure O2 concentration is not lower than 25%

O₂ flush: 35L/min～75L/min

• Select Switch: select between ACGO and Absorber

• ACGO: alone used for open breath circuit

• Selectatec Mounting bar: one station used for vaporizer, it is easy to replace vaporizer

•


Respiration System

• Absorber chamber:1000mL

• System leakage: when pressure is lower than 3kPa, ≦125L/min

• System compliance: ≦4ml/kPa

• Resistance of system:

Flow rate:30L/min﹤0.16kPa

Flow rate:60L/min﹤0.52kPa

• APL valve: 0.19～6kPa




 Dimensions of the machine:

• Height:41cm (without CO2 circle absorber) /59cm (with CO2 circle absorber)

• Width:45cm (without CO2 circle absorber) /69cm (with CO2 circle absorber)

• Depth:20cm (without CO2 circle absorber) /23cm (with CO2 circle absorber)

• Weight: 23kg (without CO2 circle absorber) / 26kg(with CO2 circle absorber)
