Features

The Altor 5 patient monitor fulfills basic clinical requirements in various environments . Covering all patient types.

• Touch operation (optional)

• High resolution 12.1 inch screen design &intuitive shortcut keys boost your working efficiency

• Handle design convenient to carry

• Connect to CMS,realizing remote monitoring

• Multiple external interfaces, built-in wifi (optional)

Six parameters

ECG, RESP, SPO2, TEMP, NIBP,PR (Pulse Rate)

Multi Display Interface

Physical Specification Dimension &weight

• Equipment:308mm × 141mm × 273mm; 3.1 kg

• Screen type / resolution：12.1"color TFT LCD /800×600 pixels

• Battery:2200mAh /14.8V ,3h operating after full charge

     charging time ：About 2.5 hours full 90%, 3 hours full

     AC: 100 ~ 240V, 50Hz/60Hz ,DC: Built-in rechargeable battery

• Monitor Interface Specifications:VGA/ 2 USB ports/RJ45 connector




Standard Accessories

• Integrated adult SPO2 sensor finger clip

• Blood pressure pipe

• 3PIN type skin TEMP probe

•  Blood pressure cuff

• Integrated ECG cable and 5-Lesd wire

• UL ground cable

• Power cable

• Disposable ECG electrodes
